Technical data
Tablet-based, kiosked mode | System solution | |
Single Laser | Laser technology | |
Coaxial, reflected laser beam | Measuring principle | |
0 – 5 m | Measuring distance | |
0° – 360° | Measuring range inclinometer | |
yes, max. 4 measuring points | Active clock mode | |
Bluetooth | Communication | |
8'' TFT, 1280 x 800 Px. | Display | |
-10°C – +50°C | Operating temperature | |
Li-Ion rechargeable battery | Voltage supply | |
up to 10 hours | Operating time | |
IP 68 | Protection class handheld | |
IP 65 | Protection class laser/sensor | |
Class 2 acc. to IEC 60825-1 | Safety class laser | |
500 x 410 x 140 | Dimensions case (mm) | |
| ≈m | 5.7 kg | Weight |
Additional information
1 pc. handheld tablet, 1 pc. charger with adapters, 1 pc. shaft bracket, 1 pc. laser/sensor, 1 pc. reflector with roof prisma, 1 pc. micro USB cable, 1 pc. USB C data cable, 1 pc. USB A USB C adapter cable, 1 pc. tape measure, 1 pc. hex wrench SW4, 1 pc. case | Included in delivery |
